Bottom-entry high-shear homogenizer with vacuum and jacketed vessel. RS, RX, RB series — 50L to 2000L working capacity, particle size down to 5 microns. SS316L mirror-polished contact parts, CE certified.
Every machine in this family is built in our own factory, hydrostatic-tested, and video-inspected before shipment. Engineers reply to inquiries within 24 hours.
Capacity: 50L – 2000L
Standard vacuum emulsifier, most popular for cosmetics and small-batch pharma. 5 micron particle size, hydraulic lift lid from RS-300.
Capacity: 100L – 2000L
Heavy-duty vacuum emulsifier for production-scale runs. Full hydraulic lid and bottom valve, higher-power homogenizer for tougher formulations.
Capacity: 100L – 2000L
Bottom-entry homogenizer paired with anchor stirrer, designed for higher-viscosity creams and pastes.
Capacity: 50L – 500L
Cost-effective variant of RS without vacuum — ideal for non-air-sensitive formulations and budget buyers.
Capacity: 100L – 500L
Simplified RX without vacuum for budget production runs.
Indicative specs. Final spec sheet issued with your formal quotation.
| Capacity range | 50L – 2000L working |
|---|---|
| Material (contact) | SS316L, mirror-polished Ra ≤ 0.4μm |
| Homogenizer power | 4 kW – 22 kW |
| Homogenizer speed | 3000 rpm standard |
| Particle size | Down to 5 microns |
| Vacuum | −0.09 MPa (water-ring pump) |
| Heating/cooling | Jacketed vessel, electric or steam |
| Lid | Manual (≤200L) / Hydraulic (≥300L) |
| Discharge | Bottom valve |
| CE | Yes — EU Declaration of Conformity supplied |
50L · 4 kW homogenizer
100L · 4 kW homogenizer
200L · 5.5 kW homogenizer
300L · 7.5 kW homogenizer
500L · 11 kW homogenizer
1000L · 15 kW homogenizer
100L · 4 kW homogenizer
200L · 5.5 kW homogenizer
300L · 7.5 kW homogenizer
500L · 11 kW homogenizer
1000L · 15 kW homogenizer
2000L · 22 kW homogenizer
100L · 4 kW homogenizer
200L · 7.5 kW homogenizer
300L · 7.5 kW homogenizer
500L · 11 kW homogenizer
1000L · 15 kW homogenizer
2000L · 22 kW homogenizer
Tell us your product, batch size and capacity. We'll recommend the right model from this family and quote it.
Request a Quote →
